PVC Layflat Hose
PVC One-Step Extrusion Layflat Hose
PVC One-Step Extrusion Layflat Hose from WANRUIGUDE New Materials. Material: PVC resin + high-strength polyester industrial filament. Working pressure: 0.3~0.6 MPa (3~6 bar).
Specifications
- Product Series
- TW-PVC-03
- Material
- PVC resin + high-strength polyester industrial filament
- Construction
- One-step extrusion molding, polyester braided reinforcement layer and PVC inner/outer coating formed simultaneously in one piece, no delamination
- Color
- Blue, yellow, black, red (customizable)
- Size Range
- Inner diameter 25mm~200mm (1"~8")
- Working Pressure
- 0.3~0.6 MPa (3~6 bar)
- Burst Pressure
- ≥3 times working pressure (0.9~1.8 MPa)
- Temperature Range
- < 75°C
- Standard Length
- 20m / 50m / 100m (customizable)
- MOQ
- 5000 meters (standard specifications)
- Lead Time
- 10~15 days
- Customization
- Color, length, pressure rating, wall thickness, printed logo, fitting accessories
PVC One-Step Extrusion Layflat Hose is a B2B hose option built from PVC resin + high-strength polyester industrial filament. Typical source-listed applications include Agricultural irrigation, garden sprinkler irrigation, industrial and mining water supply/drainage, construction engineering drainage, municipal water supply.
Construction: One-step extrusion molding, polyester braided reinforcement layer and PVC inner/outer coating formed simultaneously in one piece, no delamination The supplied master sheet lists a working-pressure range of 0.3~0.6 MPa (3~6 bar) and a burst-pressure range of ≥3 times working pressure (0.9~1.8 MPa).
Documented size range: Inner diameter 25mm~200mm (1"~8"). Documented standard length: 20m / 50m / 100m (customizable). Documented temperature range: < 75°C.
Source-listed performance features include Tensile and fracture resistant, high pressure resistance with low expansion rate, lightweight and flexible, corrosion and aging resistant, wear and UV resistant, maintains elasticity at low temperatures, odorless and eco-friendly.
For selection and quotation, provide the conveyed medium, application, required inside diameter, length, operating pressure or vacuum, coupling type, quantity and destination. Commercial reference: documented MOQ 5000 meters (standard specifications); documented lead time 10~15 days. Available customization: Color, length, pressure rating, wall thickness, printed logo, fitting accessories.
