PVC Layflat Hose
PVC Coated Layflat Hose
PVC Coated Layflat Hose from WANRUIGUDE New Materials. Material: Modified PVC resin coating + high-strength polyester yarn/polyester fiber braided layer.
Specifications
- Product Series
- TW-PVC-04
- Material
- Modified PVC resin coating + high-strength polyester yarn/polyester fiber braided layer
- Construction
- High-strength polyester yarn circular woven tubular reinforcement layer, double-sided PVC resin coating on both inner and outer surfaces, three-layer composite structure
- Color
- Blue, yellow, red, black, green (customizable)
- Size Range
- Inner diameter 25mm~200mm (1"~8")
- Working Pressure
- 0.3~0.6 MPa (3~6 bar)
- Burst Pressure
- ≥3 times working pressure (0.9~1.8 MPa)
- Temperature Range
- < 75°C
- Standard Length
- 20m / 50m / 100m (customizable)
- MOQ
- 5000 meters or 1 ton (standard specifications)
- Lead Time
- 10~15 days
- Customization
- Color, length, pressure rating, wall thickness, UV anti-aging level, printed logo, fitting type
PVC Coated Layflat Hose is a B2B hose option built from Modified PVC resin coating + high-strength polyester yarn/polyester fiber braided layer. Typical source-listed applications include Agricultural irrigation, landscaping, industrial water supply and drainage, construction drainage, flood control and drainage, mine water diversion, fire water supply.
Construction: High-strength polyester yarn circular woven tubular reinforcement layer, double-sided PVC resin coating on both inner and outer surfaces, three-layer composite structure The supplied master sheet lists a working-pressure range of 0.3~0.6 MPa (3~6 bar) and a burst-pressure range of ≥3 times working pressure (0.9~1.8 MPa).
Documented size range: Inner diameter 25mm~200mm (1"~8"). Documented standard length: 20m / 50m / 100m (customizable). Documented temperature range: < 75°C.
Source-listed performance features include Hydrolysis resistant, UV resistant, weak acid and alkali resistant, good flexibility with no creases after folding, lightweight and portable, wear and pressure resistant, bright color with smooth coating surface.
For selection and quotation, provide the conveyed medium, application, required inside diameter, length, operating pressure or vacuum, coupling type, quantity and destination. Commercial reference: documented MOQ 5000 meters or 1 ton (standard specifications); documented lead time 10~15 days. Available customization: Color, length, pressure rating, wall thickness, UV anti-aging level, printed logo, fitting type.
